| Rack-mountable – 1U |
Enclosure type |
| 48x 10/100/1000 + 4 x 1G SFP |
Ports |
| 10/100Mbps Ethernet (RJ-45) |
Network management Interface |
| 370W |
Available PoE Power |
| 108Gbps |
Forwarding bandwidth(Gbps) |
| 8 |
Maximum stacking number |
| 80G |
Stack Bandwidth |
| 107.1Mpps |
Forwarding Performance |
| 216Gbps |
Switching bandwidth |
| 1023 |
Maximum active VLANs |
| 16K (default) |
MAC Address Table Size |
| APM86392 600MHz dual core |
CPU |
| 256MB |
RAM |
| 64MB |
Flash Memory |
| Per-port status: Link integrity, disabled, activity, speed, and full duplex System status: System, RPS, Stack link status, link duplex, PoE, and link speed |
Status Indicators |
|
Expansion / Connectivity |
| USB (Type-B), Ethernet (RJ-45) |
Console ports |
| Optional |
Stacking cable |
| Option (PWR-RPS2300) |
Power Redundancy |
| 110V-240V |
Voltage range (Auto) |
| 0.49KVA |
Power Consumption Operational |
|
Miscellaneous |
| 17.5Inches (44.5 cm) |
Width |
| 14.5Inches (36.8 cm) |
Depth |
| 1.75Inches (4.5 cm) |
Height |
| 12.9lb (5.8 Kg) |
Weight |
| 23.48lb (10.65 Kg) |
Package Weight |
| optional |
Rack Mounting Kit |
| 205052 |
MTBF in hours |
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1p CoS Prioritization
IEEE 802.1Q VLAN
IEEE 802.1s
IEEE 802.1w
IEEE 802.1X
IEEE 802.1ab (LLDP)
IEEE 802.3ad
IEEE 802.3af and IEEE 802.3at
IEEE 802.3ah (100BASE-X single/multimode fiber only)
IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-X
RMON I and II standards
SNMP v1, v2c, and v3
IEEE 802.3az
IEEE 802.1ax |
Compliant Standards |
|
System software / license |
| IOS LAN BASE |
System software |
| NERGY-MGT-100-K9, EW-DO-100-DE |
license |
Jumbo Frames
VLANS
Voice Vlan
VTPv2
CDPv2
LLDP
802.3ad LACP
PVST/PVST+
802.1W/802.1S
Port Fast/Uplink Fast
port CoS Trust and Override
Scheduling
Priority Queuing
Configure CoS Priority Queues
Weighted Tail Drop
DSCP transparency |
features |
SSH, SSL and SCP
+RADIUS and TACACS
SNMPv3 crypto
802.1x
802.1x Accounting / MIB
802.1x w/ port security
802.1x w/Voice VLAN
802.1x Guest VLAN
802.1x VLAN assignment
802.1x MAC-Auth Bypass
BPDU/Root Guard
Port Security
Private VALN Edge
Storm Control
Block unknown unicast and multicast
IGMP Snooping
IGMP Filter/Throttle |
Network security |
Auto-MDOX
TDR
UDLD
IP SLA Responder
layer 2 / IP Traceroute
SPAN
RSPAN
Express Setup
Device Manager
Cisco Network Assistant
Smartports + Advisor
Troubleshooting Advisor
Drag-and-drop Cisco IOS Upgrade
IP Address DHCP
Autoinstall with saved configuration
Configuration Replace
DHCP Auto Image Upgrade
DHCP Port Based Allocation
Error Disable MIB |
Management and Troubleshooting |
|
Environmental Ranges |
| 23ºF to 113ºF (-5ºC to 45ºC) |
Operating temperature up to 5000 ft (1500 m) |
| 23ºF to 104ºF (-5ºC to 40ºC) |
Operating temperature up to 10,000 ft (3000 m) |
| 23ºF to 131ºF (-5ºC to 55ºC) |
Short-term exception at sea level |
| 23ºF to 122ºF (-5ºC to 50ºC) |
Short-term exception up to 5000 feet (1500 m) |
| 23ºF to 113ºF (-5ºC to 45ºC) |
Short-term exception up to 10,000 feet (3000 m) |
| 23º to 104ºF (-5ºC to 40ºC) |
Short-term exception up to 13,000 feet (4000 m) |
| 13º to 158ºF (-25º to 70ºC-) |
Storage temperature up to 15,000 feet (4573 m) |
| Up to 10,000 Feet (Up to 3000 Meters) |
Operating altitude |
Up to 13,000
(Up to 4000 Meters) |
Storage altitude |
| 10%to 95% noncondensing |
Operating relative humidity |
| 10%to 95% noncondensing |
Storage relative humidity |
